Figure 3-39 Binding A Port To An Acl - SMC Networks SMC TigerStack IV SMC6224M Management Manual

Web – Click Security, ACL, Port Binding. Mark the Enabled field for the
port you want to bind to an ACL, select the required ACL from the
drop-down list, then click Apply.
CLI – This example assigns an IP and MAC access list to port 1, and an IP
access list to port 3.
Console(config)#interface ethernet 1/1
Console(config-if)#ip access-group david in
Console(config-if)#mac access-group jerry in
Console(config-if)#exit
Console(config)#interface ethernet 1/3
Console(config-if)#ip access-group david in
Console(config-if)#

Figure 3-39 Binding a Port to an ACL

A C
CCESS ONTROL
L
ISTS
4-143
4-123
4-130
3-87
