CLI – Use the following command to display version information.
Console#show version
Unit 1
Serial number:
Service tag:
Hardware version:
Module A type:
Module B type:
Number of ports:
Main power status:
Redundant power status
Agent (master)
Unit ID:
Loader version:
Boot ROM version:
Operation code version:
Console#

Displaying Bridge Extension Capabilities

The Bridge MIB includes extensions for managed devices that support
Multicast Filtering, Traffic Classes, and Virtual LANs. You can access these
extensions to display default settings for the key variables.
Field Attributes
• Extended Multicast Filtering Services – This switch does not
support the filtering of individual multicast addresses based on GMRP
(GARP Multicast Registration Protocol).
• Traffic Classes – This switch provides mapping of user priorities to
multiple traffic classes. (Refer to "Class of Service Configuration" on
page 3-169.)
• Static Entry Individual Port – This switch allows static filtering for
unicast and multicast addresses. (Refer to "Setting Static Addresses"
on page 3-122.)
• VLAN Learning – This switch uses Independent VLAN Learning
(IVL), where each port maintains its own filtering database.
S416000963
R01
1000BaseT
1000BaseT
26
up
:not present
1
2.2.1.4
2.2.1.8
2.2.6.0
B C
ASIC ONFIGURATION
4-83
3-15
