C
ONFIGURING THE
Web – Click Port, LACP, Port Internal Information. Select a port channel
to display the corresponding information.
CLI – The following example displays the LACP configuration settings
and operational state for the local side of port channel 1.
Console#show lacp 1 internal
Port channel : 1
-------------------------------------------------------------------
Oper Key : 120
Admin Key : 0
Eth 1/1
-------------------------------------------------------------------
LACPDUs Internal:
LACP System Priority: 3
LACP Port Priority:
Admin Key:
Oper Key:
Admin State : defaulted, aggregation, long timeout, LACP-activity
Oper State:
.
.
.
3-106
S
WITCH

Figure 3-46 LACP - Port Internal Information

30 sec
128
120
120
distributing, collecting, synchronization,
aggregation, long timeout, LACP-activity
4-170
