MiiNePort E2/E3

Response

Byte # Descriptor
1 Header
2 Header
3 Header
4 Header
5 Data
6 Data
7 Data
8 Data
9 Data
10 Data
11 Data
12 Data
For example, the 10-byte response 5-2-0-6-0-0-1-1-0-1 indicates that DIO 0 is in input mode and "low" status,
DIO 1 is in output mode and "high" status, and DIO 2 is in input mode and "high" status.

C Code Example

BOOL ReadMultipleDIO(int start, int end, int *mode, int *status)
{
DIOPacketStruct packet;
packet.header.command = 5; // Read Multiple DIO Commands
packet.header.version = 2; // DIO protocol command version
packet.header.length = 2; // data length
packet.data[0] = start; // start of the DIO number
packet.data[1] = end; // end of the DIO number
send(SocketFd, (char *)&packet, sizeof(DIOHeaderStruct)+2, 0);
//Send TCP packet
//Process the returned data here
return TRUE;
}
Value Description
5 command number, fixed
2 version, fixed
0, 1, 2, 3, command status/error code (0 = okay)
4, 5, 6,
0xFF
4, 6, 8 data length, depends on the number of DIO channels
requested
0, 1 1st requested DIO channel
0: channel is in input mode
1: channel is in output mode
0, 1 1st requested DIO channel
0: channel status is low
1: channel status is high
0, 1 2nd requested DIO channel
0: channel is in input mode
1: channel is in output mode
0, 1 2nd requested DIO channel
0: channel status is low
1: channel status is high
0, 1 3rd requested DIO channel, optional
0: channel is in input mode
1: channel is in output mode
0, 1 3rd requested DIO channel, optional
0: channel status is low
1: channel status is high
0, 1 4th requested DIO channel, optional
0: channel is in input mode
1: channel is in output mode
0, 1 4th requested DIO channel, optional
0: channel status is low
1: channel status is high
