- Page 1 Moxa802.11a/b/g/n/jPCI Module WAPN008User’s Manual(4.9GHz version) www.moxa.com Second Edition, October2016 2016Moxa Inc. All rights reserved. Reproduction without permission is prohibited.
- Page 2 WAPN008User’s Manual The hardware and software described in this manual is furnished under a license agreement and may be used only in accordance with the terms of that agreement. Copyright Notice Copyright 2015 Moxa Inc. All rights reserved. Reproduction without permission is prohibited. Trademarks MOXA is a registered trademark of Moxa Inc.
-
Page 3: Table Of Contents
Table of Contents Chapter 1 Introduction Overview Specification Chapter 2 Getting Started Module Layout Block Diagram Hardware Installation Software Installation... -
Page 4: Chapter 1 Introduction
WAPN008User’s Manual Introduction Introduction Chapter 1 The following topics are covered in this chapter: Overview Specifications... -
Page 5: Overview
WAPN008PCI module is designed to provide wireless communication for Moxa industrial wireless products. It communicates via the standard 802.11a/b/g/n/j protocols on standard 2.4GHz/4.9GHz. The WAPN008uses the AR9344SoC Wireless chipset from Atheros. Specification Features WAPN008 Chipset Atheros AR9344 Baseband DSSS with DBPSK, DQPSK, CCK... - Page 6 WAPN008User’s Manual Introduction 4980 MHz Typ. 19±1.5 dBm @ 6 to 24 Mbps, Typ. 19±1.5 dBm @ 36 Mbps, Typ. 19±1.5 dBm @ 48 Mbps, Typ. 19±1.5 dBm @ 54 Mbps 802.11n (5 GHz): Typ. 18±1.5 dBm @ MCS0/8 20 MHz, Typ.
-
Page 7: Getting Started
Getting Started Chapter 2 This chapter covers the module layout, and block diagram, hardware installation of the WAPN008. Software installation is covered in the next chapter. The following topics are covered: Module Layout Block Diagram Hardware Installation... -
Page 8: Module Layout
WAPN008 User’s Manual Getting Started Module Layout Top and Bottom Block Diagram Below is a block diagram of the WAPN008. - Page 9 WAPN008 User’s Manual Getting Started Connector Locations...
- Page 10 WAPN008 User’s Manual Getting Started PCI Bus Connector PIN Assignments Function Connect to Function Connect to 3.3v 3.3v 3.3v 3.3v 3.3v 3.3v ERXD3 PHY RGMII 3.3v 3.3v ERXD2 PHY RGMII 3.3v 3.3v ERXD1 PHY RGMII 3.3v 3.3v ERXD0 PHY RGMII 3.3v...
-
Page 11: Hardware Installation
2. Screw on the WAPN008PCIcard. 3. Screw on the all the necessary chassis. Software Installation After physically installing the WAPN008, your operating system must be configured to recognize thenew system board. Step for Installation 1. Apply power to the system board. - Page 12 WAPN008 User’s Manual Getting Started Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a ClassB digital device, pursuant to Part 15 of the FCC Rules. These limits aredesigned to provide reasonable protection against harmful interference in aresidential installation.
- Page 13 This transmitter module is authorized only for use in device where the antenna may be installed such that 20cm may be maintained between the antenna and users. The final end product must be labeled in a visible area with the following: "Contains FCC ID: SLE-WAPN008 ”...
