SmartNode 100 Series ATA User Manual
About This Guide
This guide describes the SmartNode 100 Series Analog Telephone Adapter (ATA) hardware, installation, and
basic configuration.
Audience
This guide is intended for the following users:
Operators
•
Installers
•
Maintenance technicians
•
Structure
This guide contains the following chapters and appendices:
•
Chapter 1
on page 15 provides information about SN100 features and capabilities.
Chapter 2
on page 22 provides information about installing the SN100.
•
Chapter 3
on page 29 describes how to quickly configure the SN100 for basic operation.
•
Chapter 4
on page 46 describes using the SmartNode ATA home window to monitor ATA status or to use
•
the advanced settings to configure the ATA.
Chapter 5
on page 53 describes how to modify network settings.
•
Chapter 6
on page 61 describes how to modify VoIP settings.
•
Chapter 7
on page 112 describes how to modify security settings.
•
•
Chapter 8
on page 119 describes using maintenance tools.
•
Chapter 9
on page 133 describes how to contact Patton for assistance
Appendix A
on page 136 provides compliance information for the SN100
•
Appendix B
on page 139 provides specifications for the SN100
•
Appendix C
on page 143 provides example application scenarios
•
Appendix D
on page 146 is a frequently asked questions.
•
For best results, read the contents of this guide before you install the SmartNode 100.
