SmartNode 100 Series ATA User Manual

Introduction

This chapter describes the following:
Configuring the Firewall settings (see section "Firewall")
•
Configuring the Content Filter settings (see section
•
• Configuring ACL settings (see section

Firewall

This section describes configuring SN100 Series ATA IP filtering, MAC filtering, and port filtering settings.
Chose the appropriate section from the following:

"Configuring IP Filtering settings"

•
• "Configuring MAC Filtering settings"
"Configuring Port Filtering settings"
•

Configuring IP Filtering settings

Entries in the table (see
Internet. Use of such filters can be helpful in securing or restricting your local network.
Do the following to display IP Filtering settings:
1. Click on the plus button next to Security to display the sub-categories (see
2. Click Firewall. The IP Filtering window displays (see

Introduction

"ACL Setting"
on page 114
on page 115
figure 71 on page 114) are used to restrict IP addresses from the LAN accessing the
Figure 70. Security sub-categories
"Content Filter" on page 116)
on page 117)
figure 71 on page 114).
7 • Security Settings
figure 70).
113
