Overview

Congratulations on becoming the owner of the SmartNode ATA, a device that connects a normal PSTN tele-
phone to the Internet so that you can make telephone calls. The ATA provides an analog interface for PSTN,
PBX, fax machines, telephones, and other devices that require an analog port.
This user manual describes how to install the ATA, and how to customize its configuration to get the most out
of your new device.
This device has been thoroughly inspected and tested and is warranted for one year for parts and labor. If ques-
tions or problems arise during installation or use of this product, contact Patton Electronics Technical Support
at +(301) 975-1007.

Features

The SmartNode 100 ATA series are feature-rich analog telephone adapters that enable you to connect standard
telephones and make VoIP calls using your broadband connection. There is no need to replace your existing
analog telephones just because you want to enhance your phone system.
Easy to install and simple to use, the SN100 series connects standard telephones or fax machines to any Voice
over IP (VoIP) service provider.
Well equipped with at least one FXS RJ-11 phone interface, you can speak or fax as with the old fix net tele-
phone. Due to the small design you can easily place the adapter anywhere.
Features include:
• Codecs:
G.711-ulaw, G711-alaw, G729, G723
∕
G.726: 16k/24k/32k/40k bit per second (ADPCM)
∕
• Call Features:
Call Waiting, Call Transfer,
∕
Call Forward as Busy forward; Non-Answer forward; unconditional forward,
∕
Do-not-disturb (DND) support
∕
3-way conferencing
∕
• Fax Modes:
T.38 relay support
∕
G.711 pass-through
∕
Front Panel LED Indicators & Rear Panels

Front panel LEDs

Front panel indicator lights are described for the following SmartNode SN100 Series ATA models:
• SN101/1JS/E (see figure
• SN102/2JS/E (see figure 2
Overview
1). Table 1 lists the function of each front panel indicator.
on page 17). Table 2 on page 18 lists the function of each front panel indicator.
1 • General information
16
