SmartNode 100 Series ATA User Manual
2. Select the configuration file, then click the Upload button.
The configuration has been restored.

Reset the SN100 to factory default settings

Click the Reset button to clear all user-entered configuration information and return the SN100 to factory
defaults
))
The SN100 has been reset to factory defaults.

Upgrading SN100 firmware

The latest software builds are located at
Do the following to perform a firmware upgrade:
IMPORTANT
1. Click on the plus button next to Maintenance to display the sub-categories (see
2. Click Tools. The Configuration window displays (see
3. Click the Upgrade Firmware tab to bring it to the front (see
))
4. Click the Choose File button (see
image.
))
5. Select the firmware image, then click the Upload button.
The firmware has been upgraded.
Tools
https://www.patton.com/support/upgrades/
Do not power off the device during the upload. Doing so may
crash the system.
Figure 83. Upgrade Firmware window
figure 83 on page 129), then browse to the location of the firmware
figure 82 on page 128).
figure 83).
8 • Maintenance Settings
figure 76 on page 120).
129
