SmartNode 100 Series ATA User Manual
Table 6. Function/description of SN102/1JS1JO/E ATA rear panel connectors/button (Continued)
Callout
Label
4
LAN
5
Phone
6
Line
Front Panel LED Indicators & Rear Panels
Color
Black
Connects to the network by an Ethernet cable. This port enables your
ATA to be connected to an Internet Access device, e.g. router, cable
modem, ADSL modem, through a networking cable with RJ-45 con-
nectors used on 10Base-T and 100Base-TX networks.
Gray
FXS port can be connected to analog telephone or fax machine by an
RJ-11 (Gray) analog line.
Green
Connected to PBX or CO line by an RJ-11 (Gray) analog line. The
PSTN (FXO) port can be connected to the extension port of a PBX or
directly connected to a carrier's PSTN line.
1 • General information
Description
21
