Resetting The Lamp Parameters - Barco Prometheus I Safety & Instruction Manual

4. Lamp & Lamp House

4.11 Resetting the lamp parameters

C
AUTION
Lamp House. Neglecting this update will result in poor performance and short life time of the xenon lamp.
For a new lamp, how to reset the values
1. While the Lamp information window is displayed, click on Change lamp (1).
A Reset lamp parameters selection window opens (2).
2. To get new lamps, click on From new list (3).
The lamp article and serial number opens (4).
3. Fill out the article number of the new lamp (5a)
Or,
click on Select (5b) to display a list of possible article numbers (6). Select a article number (7) and click OK (8).
The software will check if the entered article number is a valid number (9).
4. Fill out the serial number of the lamp (10).
5. Click Reset lamp (11).
For a used lamp, how to set back the original values
1. While the Lamp information window is displayed, click on Change lamp (1).
A Reset lamp parameters window opens (2).
2. To get history of the used lamps, click from history (3).
The Reset lamp history selection window opens (4).
3. Click on Select (5) to display a list of possible lamps (6).
4. Select the desired lamp (7) and click OK (8).
The article number and serial number of the selected lamp is added to the Reset lamp parameters window (10). The lamp run
time and number of strikes of this lamp are added in Lamp parameter preview (12).
5. The lamp parameters can be edited by the user under personnel maintenance and responsibility. If you want to change these
parameters, check the check box in front of Edit lamp parameters (11).
The current parameter fields become active (12).
6. Click in an input field and change to the desired value.
7. Click Reset lamp (13).
66
:
The "LAMP INFO" parameters MUST be updated after each installation of a xenon lamp inside the
R5905963 PROMETHEUS SERIES 09/03/2015
