7.5

ICMP reset button and status LEDs

ICMP status LEDs and Reset button
LEDs on ICMP front panel give information on the status of the device.
3
Image 7-7
Status overview PWR/ERROR and READY LEDs:
1
PWR/ERROR
Off
Red
Blinking Green
Blinking Green
Blinking Green
Blinking Green
Blinking Green
Green
Green
Green
Blinking Red
Reset button
3
Button used to reset ICMP (reference 3 image 7-7)
C
AUTION
ICMP are always available. It is an ultimate resort in the event of complete blockage of interface.
C
AUTION
the lasers in deconditioning state before pressing the reset button and condition them again from the moment
the ICMP is rebooted (after reset). Resetting the ICMP with lasers on can create a risk as the proper operation
of the DMD cooling cannot be guaranteed in this case.
R5905963 PROMETHEUS SERIES 09/03/2015
2
READY ICMP Status
Off Turned off
Off Board reset
Off Boot loader
Blinking Orange Operating System start up
Orange Security Manager - Image Integrity tests
Blinking Yellow Security Manager - Self Test
Yellow Security Manager - FPGA self-test
Blinking Orange Update ongoing
Blinking Green FIPS ok - Application startup
Green Power on & No Error
Off FIPS error
:
It is not recommended to use the ICMP reset button if conventional means to stop and restart the
:
In case the ICMP is installed in a RGB-laser illuminated cinema projector it is recommended to put
1
2
7. ICMP
113
