Barco Prometheus I Safety & Instruction Manual page 107

Location of the source input ports (DVI)
10 / 100 / 1000 BASE-T
1
2
Image 6-10
6 DVI-D input, port A, Single link + HDCP
7 DVI-D input, port B, Single link + HDCP
In case an ICMP is installed the DVI ports of the Cinema Controller are not operational. Use a DVI-to-HDMI
adapter and connect the DVI source with the HDMI port of the ICMP.
DVI
Digital Visual Interface is a display interface developed in response to the proliferation of digital flat panel displays.
The digital video connectivity standard that was developed by DDWG (Digital Display Work Group). This connection
standard offers two different connectors: one with 24 pins that handles digital video signals only, and one with 29 pins
that handles both digital and analog video. This standard uses TMDS (Transition Minimized Differential Signal) from
Silicon Image and DDC (Display Data Channel) from VESA (Video Electronics Standards Association).
DVI can be single or dual link.
DVI Input formats
Input Source
standard
Single DVI VESA (640x480) 60
Single DVI VESA (640x480) 72
Single DVI VESA (800x600) 60
Single DVI VESA (800x600) 72
Single DVI VESA
(1024x768)
Single DVI VESA
(1024x768)
Single DVI VESA
(1280x1024)
Single DVI 1280x720
Single DVI 1920x1080
Single DVI 2048x1080
Single DVI 1920x1080i
Twin DVI ACS
(2048x1080)
Twin DVI ACS
(2048x1080)
DVI-3D 3D (2048x1080)
DVI-3D 3D (2048x1080)
DVI-3D 3D (2048x1080)
DVI-3D 3D (2048x1080)
DVI-4K 4K (4096x2160)
About DVI-4K:
Two columns of 2048x2160 are needed, where DVI-A is left image and DVI-B is right image. Use Rec 709 for 4K as PFC file.
R5905963 PROMETHEUS SERIES 09/03/2015
RS232 IN
DVI INPUT
DVI A
SEL
3
SYNC OK
6
Vertical rate
60
70
60
60
60
50/60
50/60
50/59.94
50/59.94
24/eye
25/eye
30/eye
50/eye
24
3D INTERFACE
GENERAL PURPOSE IN/OUT
DVI B
SEL
SYNC OK
7
Scan type Color space
Progressive RGB
Progressive RGB
Progressive RGB
Progressive RGB
Progressive RGB
Progressive RGB
Progressive RGB
Progressive RGB
Progressive RGB
Progressive RGB
Interlaced RGB
Progressive RGB
Progressive RGB
Progressive RGB
Progressive RGB
Progressive RGB
Progressive RGB
Progressive RGB
6. Input & communication
PERIPHERAL PORT
Sampling Color depth
4:4:4 8 bit
4:4:4 8 bit
4:4:4 8 bit
4:4:4 8 bit
4:4:4 8 bit
4:4:4 8 bit
4:4:4 8 bit
4:4:4 8 bit
4:4:4 8 bit
4:4:4 8 bit
4:4:4 8 bit
4:4:4 10 bit
4:4:4 12 bit
4:4:4 2x8 bit
4:4:4 2x8 bit
4:4:4 2x8 bit
4:4:4 2x8 bit
4:4:4 8 bit
103
