5. LENSES & LENS HOLDER
About this chapter
This chapter gives an overview of available lenses for the Prometheus and explains how you can select the best suited lens for your
specific situation using the lens calculator. Also, it is explained how to install and remove a lens from the projector lens holder and
how you can shift, zoom and focus the lens. Furthermore, it is described how you can perform the Scheimpflug adjustment.
C
AUTION
before transporting the projector. Neglecting this can damage the Lens Holder and Prism.
Each time a lens is manipulated (e.g. removed and installed in a projector), it needs to be homed and returned.
Overview
• Available lenses
• Lens selection
• Lens installation
• Lens removal
• Lens shift, zoom & focus
• Back Focal Length adjustment
• Scheimpflug adjustment
• Fixation of the Lens Holder front plate
R5905963 PROMETHEUS SERIES 09/03/2015
:
Never transport the projector with a Lens mounted in the Lens Holder. Always remove the Lens
5. Lenses & lens holder
69
