10. REMOVAL AND INSTALLATION OF THE PROJECTOR
COVERS
W
ARNING
W
ARNING
unless otherwise specified in the procedure.
Overview
• Removal of the lamp cover
• Removal of the rear cover
• Removal of the input cover
• Removal of the front cover
• Removal of the side cover
• Installation of the front cover
• Installation of the input cover
• Installation of the lamp cover
• Installation of the rear cover
• Installation of the side cover
Location of the covers
5
Image 10-1
Location of the covers
1 Lamp cover
2 Input cover
3 Front cover
4 Side cover
5 Rear cover
All cover can be individually removed.
R5905963 PROMETHEUS SERIES 09/03/2015
:
All procedures in this chapter may only be performed by "qualified service technicians" .
:
Disconnect the power to the circuit mains terminals and unplug the power cord at UPS INLET,
1
2

10. Removal and installation of the projector covers

4
3
131
