10.5 Removal of the side cover

Necessary tools
Flat screwdriver
How to remove
1. Release both captive screws on top of the side cover.
Image 10-10
Captive screws
2. Push both lock to each other to release the locks and pull at the same time the bottom side of the cover away form the projector.
Image 10-11
Unlock side cover
3. Take off the cover.
