6.6

Integrated Media Block/Server (optional)

Depending on the projector configuration the projector card cage is either equipped with an ICP or ICMP. In
case an ICP is installed then an IMB, IMS, or HDSDI input module can be optionally inserted into the slot below
the ICP. This is not the case if the ICMP is installed. For more information about the ICMP see chapter called
ICMP.
Integrated Media Block (IMB)
Image 6-7
Example of IMB powered by Doremi.
Integrated Media Server (IMS)
Image 6-8
Example of IMS powered by Doremi.
Configuration and operation instructions for IMB and IMS are not included in this document. See manufactur-
ers website of the installed IMB/IMS for technical documentation and support.
