4.3

Supported xenon lamps for the XL Lamp House

Anode and cathode lamp adapters are used to position the arc of the xenon lamp in the middle of the reflector
inside the lamp house. The size of the xenon lamp vary from type to type. Because of that different lamp
adapters are required. Futhermore, some lamp types require an anode adaptation bushing to fit precisely into
the anode support assembly. The table below shows for each supported xenon lamp which anode/cathode
adapters have to be used and if an anode adaptation bushing is required.
All lamps and adapters in the table below must be used with the XL Lamp House (either manual or motorized).
Note that the maximum lamp power the projector delivers depends on the type of projector and the installed
lamp. Prior to install the lamp it's important to check with the Communicator software if the lamp is listed in
the list of supported lamps for this projector.
Supported lamp types and their respective anode/cathode adapters for the XL Lamp House:
Lamp type /
Supplier
3000W DHS OFR
OSRAM XBO
4500W DHP-OFR
OSRAM XBO
6000W DHP-OFR
OSRAM XBO
6500W DHP-OFR
OSRAM XBO
DXL-30BA
USHIO
DXL-45BA
USHIO
DXL-60BA2
USHIO
DXL-65BA
USHIO
DXL-65BA2
USHIO
DXL-70BA
USHIO
XDC6500B
PHILIPS
W
ARNING
mance of the lamp and damage to the xenon lamp and Lamp House. Some adapters looks the same, therefore
check the engraved item number upon the adapter to ensure you uses the right adapter.
R5905963 PROMETHEUS SERIES 09/03/2015
Cathode adapter
R8436061K
R8436081K
R8436081K
R8436081K
R859984K
R8436111K
R8436111K
R8436111K
R8436111K
R8436111K
R8436081K
:
Always use the right adapter(s) for the xenon lamp. Neglecting this may result in poor perfor-
Anode adapter Anode adaptation
bushing
R859987K
R859986K
-
R864132K
-
R864132K
R859985K
-
-
-
-
-
-
R864132K
4. Lamp & Lamp House
Barco Order No.
-
R9855950
-
R9855949
R98064901
R9806860
-
R9855953
-
R9855952
-
R9806520
-
R9855951
-
R9855962
-
R9855966
R9856380
41
