2.2
Installation requirements
Environment conditions
Table below summarizes the physical environment in which the Prometheus may be safely operated or stored.
Environment
Ambient Temperature
Air cleanliness
Humidity
Altitude
Let the projector acclimatize after unpacking. Neglecting this may result in a startup failure of the Light Pro-
cessor Unit.
Cooling requirements
The projector is fan cooled and must be installed with sufficient space around the projector head, minimum 20 cm (8 inch) to ensure
sufficient air flow. It should be used in an area where the ambient temperature, as measured at the projector air inlet , does not
exceed +35°C (+95°F).
The installation of an exhaust system is MANDATORY. The installed exhaust blower must remove an air volume of minimum
10m
3
/min (350 CFM) measured at the exhaust output of the projector.
Main Power requirements
Projector
Prometheus I
Prometheus II
The power cord required to connect the projector with the power net is not delivered with the projector. It is the responsibility of the
customer to provide the correct type of power cord. The cross-sectional area of the conductors in the power supply cord shall not
be less than 4 mm² or 10 AWG, minimum 300V.
To protect operating personnel, the National Electrical Manufacturers Association (NEMA) recommends that the instrument panel
and cabinet be grounded. In no event shall this projector be operated without an adequate cabinet ground connection.
The AC supply must be installed by a qualified electrician in conformance to local codes. Hardware, wire sizes and conduit types
must comply with local codes.
A readily accessible disconnect device shall be incorporated externally to the equipment for removal of the power to the equipment
mains terminals.
The building installation must be provided with a circuit breaker of max. 40A to protect the complete unit.
W
ARNING
of all power from the unit
UPS requirements
The Uninterruptible Power Supply (UPS), also known as a Continuous Power Supply (CPS), must have an output voltage of 200-240V
at 50-60Hz and must be capable of delivering an output current of 5,5 amperes. This UPS provides only power for the electronics
and not for the lamp.
The connection between the UPS unit and the UPS inlet of the projector must be done with a certified AC power supply cord of
minimum 0,75 mm² or 18 AWG and minimum 300V.
C
AUTION
unit with power! The UPS OUTLET of the projector may only be used for connection to the UPS INLET of the
projector.
The Prometheus does not have a built in UPS unit.
R5905963 PROMETHEUS SERIES 09/03/2015
Operating
10°C (50°F) to 35°C (95°F)
Clean office environment (equivalent with cleanroom
standard ISO 14644-1 ISO Class 9)
5% to 85% RH Non-condensed
-60 (-197Ft) to 3000m (9843Ft)
Power requirements
200-240 VAC, 50-60Hz, 30A at 200 VAC (mono phase)
230/400V 3W+N+PE 16A 50-60Hz (Y connection) or 208V 3W+PE 27A 50-60Hz (Δ connection)
:
Disconnect the power to the unit mains terminals and unplug power cord at UPS inlet for removal
:
The 200–240V power outlet (UPS OUTLET) of the projector may not be used to provide the UPS
2. General
Non-Operating
-15°C (5°F) to 60°C (140°F)
n.a.
5% to 95% RH Non-Condensed
-60 (-197Ft) to 10000m (32810Ft)
15
