9. Perform a lens HOME & RETURN operation. (See user guide of the Communicator chapter Installation > Advanced > Lens
parameters)
Note: The HOME & RETURN operation enables the projector to determine the reference positions of the motorized ZOOM and
FOCUS of the installed lens.
For the lenses with a focus adjustment mounted on the lens (4K lenses) , the lens holder goes to a normal (fixed) focus
position. For these lenses, do not mechanically adjust the focus position of the lens holder, otherwise the normal position
will be lost.
C
AUTION
before transporting the projector. Neglecting this can damage the Lens Holder and Prism.
R5905963 PROMETHEUS SERIES 09/03/2015
:
Never transport the projector with a Lens mounted in the Lens Holder. Always remove the Lens
5. Lenses & lens holder
