14. Pin configurations
14.2 Pin configurations of the communication ports
RS232IN
RS232 IN
-
1
2 RXE- Receive Data (RD or RX or RXD)
3 TXE-
Transmitted Data (TD or TX or TXD)
-
4
5 GND Signal Ground (GND)
General Purpose IN/OUT
General Purpose In/Out
1 3D Input Reference P
2 3D Display Reference P
3 GPIN 3 P (reserved)
4 GPIN 4 P (reserved)
5
GPIN 5 P
6 GPIN 6 P
7 GPIN 7 P
8 GPIN 8 P
9 3D Output Reference P
10 GPOUT 2 P (reserved)
11 GPOUT 3 P (reserved)
12 GPOUT 4 P
13 GPOUT 5 P
14
GPOUT 6 P
15 GPOUT 7 P
16 GPOUT 8 P
17 reserved
18 reserved
19 reserved
Ethernet port
Pin Pair Color
1 3 white/green
green
2 3
3 2
white/orange
4 1 blue
5 1 white/blue
orange
6 2
7 4 white/brown
8 4 brown
Peripheral Port
Pin
1
176
10/100 Base-T — RJ45 port
Description
TXD+
TXD-
RXD+
—
—
RXD-
—
—
Name
+5V
-
6
-
7
-
8
-
9
- -
20 3D Input Reference N
21 3D Display Reference N
22 GPIN 3 N (reserved)
23 GPIN 4 N (reserved)
24
GPIN 5 N
25 GPIN 6 N
26 GPIN 7 N
27 GPIN 8 N
28 3D Output Reference N
29 GPOUT 2 N (reserved)
30 GPOUT 3 N (reserved)
31 GPOUT 4 N
32 GPOUT 5 N
33
GPOUT 6 N
34 GPOUT 7 N
35 GPOUT 8 N
36 reserved
37 reserved
1000 Base-T — RJ45 port
Description
TX0+
TX0-
RX0+
TX1+
TX1-
RX0-
Rx1+
RX1-
R5905963 PROMETHEUS SERIES 09/03/2015
