14.4 Pin configurations of the inputs
DVI-D
DVI IN A & B
1 RX2-
2 RX2+
3
RX2 Shield
nc
4
nc
5
6 DDC Clock
R5905963 PROMETHEUS SERIES 09/03/2015
7 DDC Data 13
nc
8 14
9 RX1- 15
10 RX1+ 16
11 RX1 Shield 17
nc
12 18
nc
19
+5V 20
21
GND
Hot Plug Detect 22
RX0- 23
RX0+ 24
14. Pin configurations
RX0 Shield
nc
nc
TMDS Clock Shield
TMDS RXC+
TMDS RXC-
