6. Input & communication
6.1

Introduction

General
The Input & Communication side of the Prometheus consists of a Local Keypad and a card cage with four slots. The rear side of
the projector is equipped with a tail light which reflects the status of the projector.
Depending on the projector configuration the projector card cage is equipped with an ICP or ICMP. See illustration below. In case
an ICP is installed then an IMB, IMS, or HDSDI input module can be optionally inserted into the slot below the ICP. Note that all
information about the ICMP is gathered into one separated chapter called ICMP.
Image 6-1
1 Fan Control Board (FCB).
2 Integrated Cinema Processor (ICP).
3 Optional slot for either IMB, IMS or HD-SDI input module.
4 Barco Cinema Controller.
5 Barco ICMP (inserted in ICP slot and optional slot).
C
AUTION
the boards (except for the Cinema Controller) will result in an authorization request upon starting.
90
:
A unit may only be removed from the card cage by qualified service personnel. Removing one of
1
2
3
4
