Barco Prometheus I Safety & Instruction Manual page 38

3. Physical installation
Always connect the ground wire (PE) with the connector indicated with PE on the terminal barrier strip.
If a neutral conductor is available, connect always to the connector indicated with N on the terminal barrier strip
Warning: Always connect first the PE wire.
3W + PE
Image 3-15
Terminal connections
6. Reinstall the power connection cover.
34
L1
L2
L3
PE
L1
L2
L3
N
PE
3W+N+PE
R5905963 PROMETHEUS SERIES 09/03/2015
