BIOS Advanced Menu Selections
Setup Options

BIOS Advanced Menu Ethernet Controller Options

The following table describes the BIOS Advanced Menu Ethernet controller options:
TABLE 29
Setup Options
Port Configuration Menu
NIC configuration
Link Speed (R/O)
Wake on LAN
Blink LEDs
Port Configuration
Information
UEFI Driver (R/O)
Adapter PBA (R/O)
220 Oracle Exadata Storage Server X5-2 High Capacity Service Manual • January 2018
Options
BIOS Advanced Menu Ethernet Controller Options
Options
Supported port speeds/
Auto Negotiate
Disable/Enabled
0/1/2/3
NA
NA
Defaults Description
press +/- keys to move the
attempt up/down in the
attempt order list.
Defaults Description
Use to configure the
network device port.
NA Specifies the port speed
used for the selected boot
protocol.
Note -
supported.
NA Enable or disable wake on
LAN.
Note -
supported.
0 Use to identify the
physical network port by
blinking the associated
LED.
Displays and specifies
the port settings for the
network device.
NA Identifies the UEFI driver.
NA Product board adapter
(PBA) number. You can
use the Intel Network
Adapter PBA number to
search for the adapter's
model number. The PBA
number is a nine digit
number that is the last part
of the adapter board serial
number. The PBA number
is presented in this format:
xxxxxxx-xxx, for example,
C80222-001.
This option is not
This option is not
