Video Connector - Oracle Exadata X5-2 Service Manual

TABLE 14
Serial Port (RJ-45 Connector)
Pin
1
2
3
4
5
6
7
8
Related Information
"Rear Panel Components and Cable Connections" on page 15
■
"Disconnect Cables From the Server" on page 54
■
"Reconnect Power and Data Cables" on page 167
■

Video Connector

The video connector is a DB-15 connector that can be accessed from the back panel.
TABLE 15
Pin
1
RJ-45 to DB-25 Adapter Crossovers Wiring Reference
Signal Description
RTS
DTR
TXD
Signal ground
Signal ground
RXD
DSR
CTS
Video Connector Signals
Signal Description
Red Video
DB-25 Adapter
Pin Signal Description
5 CTS
6 DSR
3 RXD
7 Signal ground
7 Signal ground
2 TXD
20 DTR
4 RTS
Pin Signal Description
9 [KEY]
Identifying the Server Ports
Video Connector
173
