Install SAS Storage Drive Cables
Note -
drive backplane and rear storage drive backplane.
3.
Return the server to operation.
a.
Install the server's front fan assembly door cover.
See
Lower the air baffle to the installed position.
b.
122
Oracle Exadata Storage Server X5-2 High Capacity Service Manual • January 2018
Cable part number 7064129 is required for SAS connections between the front storage
"Install the Fan Assembly Door" on page
163.
