Oracle Exadata X5-2 Service Manual page 215

Setup Options Options
Active Mgmt Port NET MGT/NET0/NET1/
NET2/NET3
Commit NA
IPv4 Configuration NA
Channel Number (R/O)
Current IPv4 IP Static/Dynamic
Assignment in BMC (R/O)
Current IPv4 address in NA
BMC (R/O)
Current IPv4 MAC NA
Address in BMC (R/O)
Current IPv4 Subnet Mask NA
in BMC (R/O)
Current IPv4 Default NA
Gateway in BMC
Refresh
IPv4 IP Assignment Static/Dynamic
IPv4 Address NA
IPv4 Subnet Mask NA
IPv4 Default Gateway NA
BIOS Advanced Menu Selections
Defaults Description
NET MGT Use to change the
currently active network
management port.
NA Commit the current BMC
network LAN information.
NA Current configuration
of the IPv4 settings is
displayed.
1 Current channel number is
displayed.
Static Set the IPV4 IP
assignment to Static or
Dynamic. This setting
determines whether
the service processor is
assigned a static IPv4
address or assigned a
dynamic IPv4 address
using Dynamic Host
Control Protocol (DHCP).
NA Displays the current IPv4
address in the BMC.
NA If IPv4 Assignment is
set to Static, set the IPv4
address for the service
processor.
Example: 172.31.255.255
NA If the IPv4 Assignment is
set to Static, set the IPv4
subnet mask.
Example: 255.255.255.0
NA If the IPv4 Assignment is
set to Static, set the IPv4
default gateway
Example: 172.31.255.255
Refresh the current BMC
LAN information.
Static Current IPv4 assignment.
NA If set, current IPv4 address
is displayed.
NA If set, current IPv4 Subnet
Mask is displayed.
NA If set, current IPv4 Default
Gateway is displayed.
BIOS Setup Utility Menu Options 215
