Memory Device Components

The following table lists the memory device components.
Component Name (Oracle ILOM CLI
Targets)
/SYS/MB/P[0-x]/D[0-11]
/SYS/MB/P[0-x]/D[0-11]/PRSNT
/SYS/MB/P[0-x]/D[0-11]/SERVICE
Related Information
"System Chassis Components" on page 231
■
"Cooling Unit Components" on page 233
■
"Disk Backplane Components" on page 234
■
"Power Unit Components" on page 236
■
"Processor Components" on page 237
■
"System Board Components" on page 237
■
"System Firmware Components" on page 239
■
IPMI Type Description
FRU Host CPU DIMM
FRU
Discrete Host CPU DIMM is
sensor present.
Indicator Host CPU DIMM
Service Required
LED
Monitoring Components and Identifying SNMP Messages
Monitoring System Components
Values (if applicable)
01h-ENTITY_ABSENT
02h-ENTITY_PRESENT
Color: Amber
Location: Mainboard
Off: Normal
On: DIMM was diagnosed as
faulty.
235
