Related Information
See "Troubleshoot Hardware Faults Using the Oracle ILOM Web Interface" on page 23
■
Troubleshoot Hardware Faults Using the Oracle ILOM Web
Interface
The screens shown in this procedure might differ from those for your server.
Note -
This procedure uses the basic troubleshooting steps described in
Process" on page 22.
Use this procedure to troubleshoot hardware faults with the Oracle ILOM web interface and, if
necessary, prepare the server for service.
This procedure provides one basic approach to troubleshooting hardware faults. It
Note -
uses a combination of the Oracle ILOM web interface and command-line interface (CLI).
However, the procedure can be performed using only the Oracle ILOM CLI interface. For
more information about the Oracle ILOM web interface and CLI, refer to the Oracle ILOM
documentation.
Before beginning this procedure, obtain the latest version of the system product notes.
On a system with network access to the server, open a browser window.
1.
2. In the web browser address bar, type the IP address or host name of the service
processor (SP), and then press Enter.
The Oracle ILOM login page appears.
3. Log in to the Oracle ILOM web interface.
Enter a user name (with administrator privileges) and password at the log-in screen. The Oracle
ILOM Summary Information page appears.
The Status section of the Summary screen provides information about the server subsystems,
including:
Processors
■
Memory
■
Power
■
Cooling
■
Troubleshoot Hardware Faults Using the Oracle ILOM Web Interface
"Basic Troubleshooting
Troubleshooting and Diagnostics 23
