Accessing the BIOS Setup Utility

Related Information
Oracle Integrated Lights Out Manager (ILOM) 3.2 Documentation Library at:
■
oracle.com/goto/ilom/docs
Accessing the BIOS Setup Utility
The BIOS Setup Utility provides five main menus that you can use to view product information,
and to configure, enable, and disable, or manage system components.
This section provides the following information:
"BIOS Setup Utility Menus" on page 178
■
"BIOS Key Mappings" on page 179
■
"Access BIOS Setup Utility Menus" on page 179
■
"Navigate BIOS Setup Utility Menus" on page 181
■

BIOS Setup Utility Menus

The following table provides descriptions for the top-level BIOS Setup Utility menus.
TABLE 17
Menu
Main
Advanced
Boot
IO
Exit
See "BIOS Setup Utility Menu Options" on page 203
178 Oracle Exadata Storage Server X5-2 High Capacity Service Manual • January 2018
BIOS Setup Utility Menus Summary
Description
General product information, including memory, time/date, security settings, system serial
number, and CPU and DIMM information.
Configuration information for the CPU, trusted computing, USB, and other information. Set
the IP address for the server SP.
When operating in UEFI Boot Mode, Runtime UEFI driver configuration settings let
Note -
you manage PCIe drivers for all configurable devices.
Set the boot mode to Legacy BIOS or UEFI BIOS, and configure the boot device priority.
Manage configuration settings for I/O devices, such as I/O virtualization settings, and enable
and disable Option ROMs.
Save changes and exit, discard changes and exit, discard changes, or restore the default BIOS
settings.
for examples of each of these screens.
