Remove a Storage Drive
4.
On the drive you plan to remove, push the latch release button to open the drive
latch [1, 2].
Figure
Legend
1
2
Caution -
damage the latch.
64
Oracle Exadata Storage Server X5-2 High Capacity Service Manual • January 2018
Description
Pressing the latch release button.
Opening the latch.
The latch is not an ejector. Do not open the latch too far to the right. Doing so can
