Install the Server Top Cover
Caution -
internal latch that is located on the underside of the cover might be damaged.
3. Gently slide the cover toward the front of the chassis until it latches into place
(with an audible click).
As you slide the cover toward the front of the server, watch the green release button. You will
hear an audible click when the green release button pops up, indicating that the cover is locked.
Related Information
"Remove the Server Top Cover" on page 58
■
162 Oracle Exadata Storage Server X5-2 High Capacity Service Manual • January 2018
If the top cover is not correctly positioned before you attempt to latch the cover, the
