Servicing PCIe Cards

See
e. Power on the server.
See
Verify that the AC OK LED is lit.
6. (Optional) Use Oracle ILOM to clear server DDR4 DIMM faults.
DDR4 DIMM faults are automatically cleared after a new memory DIMM has been installed.
If you need to manually clear DDR4 DIMM faults, refer to the Oracle Integrated Lights Out
Manager (ILOM) 3.2 Documentation Library at: http://www.oracle.com/goto/ilom/docs.
Related Information
"DIMM and Processor Physical Layout" on page 78
■
"DIMM Population Rules" on page 79
■
"DIMM Rank Classification Labels" on page 79
■
"Identify and Remove a Faulty DIMM" on page 81
■
Servicing PCIe Cards
These sections describe how to service and install PCIe cards. Refer to your PCIe card
documentation for complete software and cabling information about your card.
Caution -
SAS PCIe RAID HBA card that is located in PCIe slot 6.
Caution -
electrostatic discharge. This sensitivity can cause the components to fail. To avoid
damage, ensure that you follow antistatic practices as described in
Measures" on page
Caution -
PCIe cards. You must disconnect all power cables from the system before performing these
procedures.
This section covers the following topics:
"PCIe Slot Locations" on page 87
■
86 Oracle Exadata Storage Server X5-2 High Capacity Service Manual • January 2018
"Reconnect Power and Data Cables" on page
"Power On the Server" on page
The procedures in this section should not be used to service the Oracle Storage 12 Gb
These procedures require that you handle components that are sensitive to
57.
Ensure that all power is removed from the server before removing or installing
167.
167.
"Take Antistatic
