Remove a Power Supply
For instructions for disconnecting the CMA left-side connectors, see
Management Arm" in Oracle Exadata Storage Server X5-2 High Capacity Installation
Caution -
support the CMA so that it does not hang down under its own weight and stress the right-side
connectors; otherwise, the CMA might be damaged. You must continue to support the CMA
until you have reconnected both of the left-side connectors.
4. Disconnect the power cord from the faulty power supply.
5. Grasp the power supply handle and push the power supply latch to the left [1].
6. Pull the power supply out of the chassis [2].
Caution -
supply; otherwise, the server might overheat due to improper airflow.
Continue to
7.
Related Information
"Rear Panel Components and Cable Connections" on page 15
■
"Power Supply Status Indicators" on page 29
■
"Install a Power Supply" on page 75
■
74 Oracle Exadata Storage Server X5-2 High Capacity Service Manual • January 2018
When disconnecting the CMA left-side connectors, be sure to use your arm to
Whenever you remove a power supply, you should replace it with another power
"Install a Power Supply" on page
"Remove the Cable
75.
