Cooling Unit Components

The system has 3.5-inch fan modules with two fans in each module. The following table lists
the system cooling unit components.
Component Name (Oracle ILOM
CLI Targets)
/SYS/MB/FM[0-3]
/SYS/MB/FM[0-3]/F[0-x]
/SYS/MB/FM[0-3]/PRSNT
/SYS/MB/FM[0-3]/F[0-x]/TACH
/SYS/MB/FM[0-3]/SERVICE
Related Information
"System Chassis Components" on page 231
■
"Disk Backplane Components" on page 234
■
"Memory Device Components" on page 235
■
"Power Unit Components" on page 236
■
"Processor Components" on page 237
■
"System Board Components" on page 237
■
"System Firmware Components" on page 239
■
IPMI Type Description
FRU Fan module FRU
FRU Individual fan
Discrete Fan module is present.
sensor
Threshold Fan module fan speed
sensor
Indicator Fan Service Required LED
Monitoring Components and Identifying SNMP Messages
Monitoring System Components
Values (if applicable)
01h-ENTITY_ABSENT
02h-ENTITY_PRESENT
RPM
Color: Amber
Location: Mainboard
Off: Normal
On: Fan module was
diagnosed as faulty.
