Servicing the Storage Drive Backplanes

Related Information
"Remove a Processor" on page 100
■
Servicing the Storage Drive Backplanes
To remove and install the storage drive backplanes, follow the procedures in these sections.
Caution -
the storage drive backplane. You must disconnect the power cables before performing this
procedure.
"Remove the Storage Drive Backplane" on page 112
■
"Install the Storage Drive Backplane" on page 116
■
Related Information
"Servicing Storage Drives and Rear Drives" on page 61
■
"Servicing SAS Cables" on page 118
■

Remove the Storage Drive Backplane

1. Prepare the server for service.
a. Power off the server and disconnect the power cords from the power
supplies.
See
b. Extend the server into the maintenance position.
See
c. Attach an antistatic wrist strap to your wrist, and then to a metal area on the
chassis.
See
112 Oracle Exadata Storage Server X5-2 High Capacity Service Manual • January 2018
Ensure that all power is removed from the server before removing or installing
"Powering Down the Server" on page
"Extend the Server to the Maintenance Position" on page
"Take Antistatic Measures" on page
51.
55.
57.
