Oracle Exadata X5-2 Service Manual page 232

Monitoring System Components
Component Name (Oracle
ILOM CLI Targets)
/SYS/OK
/SYS/SERVICE
/SYS/LOCATE
/SYS/HOST_ERR
/SYS/PS_FAULT
/SYS/FAN_FAULT
Related Information
"Cooling Unit Components" on page 233
■
232 Oracle Exadata Storage Server X5-2 High Capacity Service Manual • January 2018
IPMI Type Description
Indicator Power OK LED
Indicator Service Required LED
Indicator Locator LED
Discrete Host asserted error sensor
sensor
Indicator Rear Power Supply Fault LED
Indicator Top Fan Fault LED
Values (if applicable)
Color: Green
Location: Front panel
Off: Power is off.
Standby blink: Standby power is on;
Oracle ILOM SP is running.
Slow blink: Startup sequence
initiated on host.
On: Host is booting OS or running
the OS.
Color: Amber
Location: Front panel
Off: Normal
On: Server requires service.
Color: White
Location: Front and rear panels
Off: Normal
Fast blink: Locate function is
activated; self-extinguishes after 30
minutes.
01h-Deasserted
02h-Asserted
Color: Amber
Location: Mainboard
Off: Normal
On: General power supply fault
Color: Amber
Location: Mainboard
Off: Normal
On: General fan fault
