cue 3. With cue 3 we can see that fixtures 41 and 43 fade in the position and color. So now they are ready for cue
4.
Cue timings
Now run cue 4. This will give values to all the fixtures we programmed in cue 5 so they are ready. Notice that fixtures
41 and 43 turned on. Keep an eye on them as you press Go + . See how they are changing color and moving
while they fade out. So MIB fixes the problem of presetting the fixtures, but since we stored it as Cue Only then they
'll move back to their default position and color as we go into cue 5. This is not what we want. We really want to
delay the color and the movement until it's finished fading out.
Have a look in the cue list. Since we added a lot of new fixtures, we can now use most of the time columns. Locate
the Position Delay column and press and hold the cell where it interacts with cue 5. This should display the
Calculator where you can set the delay time for all position moments in the transaction from cue 4 into 5. Set the
delay to 5 seconds. Do the same in the Color Delay column. We can even fine tune it a little bit more. Since we
now wait until the dimmer has faded out, we don't need then to do a position and color change in 5 seconds. The
color is just a small internal part of the fixtures, so they can move in zero seconds. The pan/tilt movement is more
visible and we should give it a little time to do the movement. Give it 1 second. This should be your final result:
This works because nothing else moves or changes color in this cue. Otherwise we would have to make a cue in
between 4 and 5.
Group master
Now if we imagine that we are going to play this show and that the audience love it, they might want multiple
curtain calls. Our small but cool imaginary theater actually has a curtain and the stage manager want to use this
instead of going back in our BO cue. So, we need to be able to remove all our front lights. This is best done using a
group master that can limit the output from the FOH group.
Clear your programmer and activate group All FOH - how nice we already had that :-) With this selection in our
programmer, press Store Group and then one of the keys associated with executor number 6. Now this works as
a group inhibitor. This means that the output of the FOH fixtures are limited by this master. When it's at 100% then
they all have full range of output. If you put this master to 50%, then this is their output limit. The output is scaled.
This means that if a fixture is stored at 50% in the cue and you move the master to 50% then the output goes to
50% of 50% - which is 25%. So it's very important that you remember to put all the Group masters back to 100% for
your show.
Master Rate and Magic Speed
