Installation
Hint:
Install the grandMA3 xPort Node DIN-Rail on the rail following DIN EN 60715.
Important:
Install the grandMA3 xPort Node DIN-Rail horizontally so that the input terminal is located at the bottom and the DMX
terminal on top.
Warning:
In order for the device to dissipate heat, comply with a minimum distance of 30 mm (approx. 2 inches) above and
beneath the grandMA3 xPort Node DIN-Rail.
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the grandMA3 and is the answer not in the manual?

Questions and answers

Summary of Contents for MA lighting grandMA3

  • Page 1 Hint: Install the grandMA3 xPort Node DIN-Rail on the rail following DIN EN 60715. Important: Install the grandMA3 xPort Node DIN-Rail horizontally so that the input terminal is located at the bottom and the DMX terminal on top. Warning: In order for the device to dissipate heat, comply with a minimum distance of 30 mm (approx. 2 inches) above and...
  • Page 2 1. Install the grandMA3 xPort Node DIN-Rail onto the rail. Place the grandMA3 xPort Node DIN-Rail on the rail...
  • Page 3 Snap it into place 2. Build the xPort Node DIN-Rail into the switchboard.
  • Page 4 Connections Connect with electrical grid -or-...
  • Page 5 Connect via PoE...
  • Page 6 Power Connector MC 1.5/ 3-ST1-5.08 Rigid cables 0.75 mm² - 1.5 mm² (18-16 AWG) 0.75 mm² - 1.5 mm² (18-16 AWG) Flexible cables Wire end sleeves are permitted. Wire stripping length 7 mm Tightening torque 0.22 Nm - 0.25 Nm Connector FK-MC 0.5/ 3-ST-2.5 Rigid cables...
