Creating a Registration Rule

Registration rules enable the SCG to assign an AP to an AP zone automatically
based on the rule that the AP matches.
Follow these steps to create a registration rule.
1 Go to System > AP Settings > AP Registration.
2 Click
3 In Rule Description, type a brief description of this rule.
4 Select the Zone Name to which this rule applies.
5 In Rule Type, click the basis upon which you want to create the rule. Options
include:
• IP Address: If you select this option, type the From (starting) and To (ending)
IP address that you want to use.
NOTE: The format of the IP address or addresses that you need to enter here
depends on the AP IP mode that you selected when you created the AP zone to
which this rule will be assigned. If you selected IPv4 Only, enter an IPv4 address. If
you selected IPv6 Only, enter an IPv6 address. If you select Dual, enter either an
IPv4 or IPv6 address.
• Subnet: If you select this option, type the network address and subnet mask
pair to use for matching.
• GPS Coordinates: If you select this option, type the GPS coordinates to use
for matching. Access points that have been assigned the same GPS coor-
dinates will be automatically assigned to the AP zone that you will choose in
the next step.
You can choose the Rule Type as GPS coordinates, wherein you must provide
information about the latitude, longitude and distance to determine if the AP
is within the defined area.
• Provision Tag: If the access points that are joining the SCG have been
configured with provision tags, click the Provision Tag option, and then type
a tag name in the Provision Tag box. Access points with matching tags will
be automatically assigned to the AP zone that you will choose in the next step.
NOTE: Provision tags can be configured on a per-AP basis from the access point's
command line interface.
6 Click OK.
SmartCell Gateway 200 Getting Started Guide for SmartZone 3.5.1, 800-71517-001 Rev A
. The AP Registration Rule form appears.
