Ruckus Wireless SmartCell Gateway 200 Getting Started Manual page 61

Table 12. New zone settings
Field
Radio Options b/g/n
(2.4 GHz)
SmartCell Gateway 200 Getting Started Guide for SmartZone 3.5.1, 800-71517-001 Rev A
Description
Indicates the radio option 2.4 GHz
configurations.
Configuring the SCG for the First Time
Your Action
Select the following options:
• Channelization—Set the channel
width used during transmission to
either 20 or 40 (MHz), or select
Auto to set it automatically.
• Channel—Select the channel to
use for the b/g/n (2.4GHz) radio,
or select Auto to set it
automatically.
• TX Power—Select the preferred
TX power, if you want to manually
configure the transmit power on
the 2.4GHz radio. By default, TX
power is set to Full on the 2.4GHz
radio.
• WLAN Group (AP Groups)—
Specify the WLAN group to which
this AP group belongs.
Creating an AP Zone
61
