b If you clicked IPv4 and IPv6 at the beginning of this procedure, under the
IPv6 section, click Auto Configuration if you want the management (web)
interface to obtain its IP address from Router Advertisements (RAs) or from
a DHCPv6 server on the network. If you want to manually assign the IPv6
network address, click Static, and then set the values for the following:
- IP address (IPv6): Enter an IPv6 address (global only) with a prefix length
(for example, 1234::5678:0:C12/123). Link-local addresses are
unsupported.
- Gateway: Enter an IPv6 address (global or link-local) without a prefix
length. Here are examples:
•
•
5 At the bottom of the screen (see
to set as the default system gateways for IPv4 and IPv6 (if enabled), and then
type the primary and secondary DNS server addresses.
NOTE: The appropriate interface to use as the default system gateway depends
on the topology of your network. See
Default Gateway
Figure 23. Select the IPv4 (and IPv6, if enabled) default system gateway
SmartCell Gateway 200 Getting Started Guide for SmartZone 3.5.1, 800-71517-001 Rev A
Global address without a prefix length: 1234::5678:0:C12
Link-local address without a prefix length: fe80::5678:0:C12
for more information.
Running the Setup Wizard and Logging On to the Web Interface
Step 2: Configure the Management IP Address Settings
Figure 23), select the interface that you want
Important Notes About Selecting the System
