3 From the zone and AP group tree, select the zone for which you want to create
an AAA server.
4 Click
5 In the General Options section, configure the following settings:
• Name: Type a name for the AAA server that you are adding.
• Description: Type a description for the AAA server that you are adding.
• Type: Click the option for the AAA server type that you want to add. Options
include RADIUS, Active Directory, and LDAP.
• Backup RADIUS: If a backup RADIUS server exists on the network, you may
enable RADIUS backup support by selecting the Enable Secondary Server
check box.
6 Configure the AAA server settings. The settings that you need to configure
depend on the server type that you selected.
• If you selected RADIUS, complete the configuration below.
- IP Address: Type the IP address of the AAA server.
- Port: Type the AAA port number. The default AAA port number is 1812.
- Shared Secret: Type the AAA shared secret.
- Confirm Secret: Retype the AAA shared secret that you typed above.
If you selected the Enable Secondary Server check box, the Secondary
Server section is visible. Configure the following Secondary Server settings:
- IP Address: Type the IP address of the secondary AAA server.
- Port: Type the AAA port number. The default AAA port number is 1812.
- Shared Secret: Type the AAA shared secret.
- Confirm Secret: Retype the AAA shared secret that you typed above.
• If you selected Active Directory, complete the configuration below.
- IP Address: Type the IP address of the AD server.
- Port: Type the port number of the AD server. The default port number
(389) should not be changed unless you have configured the AD server
to use a different port.
- Windows Domain Name: Type the Windows domain name assigned to
the AD server (for example, domain.ruckuswireless.com).
• If you selected LDAP, complete the configuration below.
- IP Address: Type the IP address of the LDAP server.
SmartCell Gateway 200 Getting Started Guide for SmartZone 3.5.1, 800-71517-001 Rev A
. The Create AAA Server form appears.
