Hotspot 2.0 Profile - Ruckus Wireless SmartCell Gateway 200 Getting Started Manual

• Authentication Service: Choose the RADIUS Accounting server that you want to
use for this WLAN. You must have added a RADIUS Accounting server previ-
ously. Additionally, if you want the controller to proxy accounting messages to
the AAA server, select the Use the Controller as Proxy check box.

Hotspot 2.0 Profile

These options only appear when Authentication Type is set to Hotspot 2.0 Access.
• Hotspot 2.0 Profile: Select the profile, which includes operator and identify
provider profiles, to use.
• Authentication Service (RFC 5580): Select the Enable RFC 5580 Location
Delivery Support check box of you want to support RFC 5580 location delivery
on the WLAN, which carries location information in RADIUS exchanges.
• Accounting Service (Updates): Configure the account update interval for
accounting servers defined in the Hotspot 2.0 Identity Provider profile.
WeChat Portal
These options only appear when Authentication Type is set to WeChat.
• WeChat Portal: Select the WeChat portal that you want to use for this WLAN.
• Accounting Service: Select the server to use for accounting messages. By
enabling proxy, accounting messages are sent by the controller. In a non-proxy
mode, the AP will communicate accounting messages directly.
Options
• Wireless Client Isolation: This option appears only when Standard Usage is
selected as the WLAN usage type. Wireless client isolation enables subnet
restrictions for connected clients. Click Enable if you want to prevent wireless
clients associated with the same AP from communicating with each other locally.
The default value is Disable.
• Isolation Whitelist: Define the destinations on the local subnet that can be
reached, even if client isolation is enabled.
NOTE: The whitelist is not applied to tunneled WLANs.
SmartCell Gateway 200 Getting Started Guide for SmartZone 3.5.1, 800-71517-001 Rev A
Configuring the SCG for the First Time
Defining the WLAN Settings of a Zone
81
