Ruckus Wireless SmartCell Gateway 200 Getting Started Manual page 18

NOTE: The power supply locations (numbers 5 and 6) are for AC or DC power. AC
power supply is pictured.
Table 5. SCG rear panel parts
Number
1
2
3
4
5
6
7
8
9
10
11
12
SmartCell Gateway 200 Getting Started Guide for SmartZone 3.5.1, 800-71517-001 Rev A
Description
Cable connector
Two low-profile PCIe interface cards that include four ports – one for
management traffic and three for redundancy. See
on the SCG.
PCIe add-in card slot for DataPlane1
PCIe add-in card slot for DataPlane0
Power supply 2
Power supply 1
RJ45 serial port (COM2/serial B). Use only the console cable provided to
connect this port to another device.
CAUTION!
The SCG has two RJ45 serial ports – one on the front panel
and one on the rear panel. You can only use one of these two ports at any
given time. Using them simultaneously may cause both serial ports to
become unresponsive.
NOTE: For information on how to access and use the SCG command line
interface, refer to the Command Line Interface Reference Guide.
Video connector
USB 0 and 1 (#1 on top)
USB 2 and 3 (#3 on top)
ETH0 GbE NIC for control (between access points and the SCG controller)
traffic
ETH1 GbE NIC for cluster traffic
