You have completed creating your first WLAN.

General Options

• Name: Type user-friendly administrative name for the WLAN.
• SSID: Type the SSID that you want to assign to the WLAN.
• Description: Enter a brief description of the qualifications or purpose of this
WLAN (for example, Engineering or Voice).
• Zone: Select the zone to which the WLAN settings apply.
• WLAN Group: Select the WLAN groups to which the WLAN configuration
applies.
WLAN Usage
• In Access Network, define the data plane tunneling behavior by either:
• Selecting the check box to tunnel the data traffic to a central data plane.
• Clearing the check box if you want APs to perform local breakouts.
• In Core Network, define the network mode by selecting one of the following
options:
• Bridge
• L2oGRE
• TTG+PDG
• Mixed Tunnel Mode
NOTE: The Core Network options are only available if the Access & Core
Separation check box is selected on the Control Plane configuration page.
• In Authentication Type, define the type of authentication flow that you want to
use for the WLAN.
• Standard usage (For most regular wireless networks): This is a regular
WLAN suitable for most wireless networks.
• Hotspot service (WISPr): Click this option if want to use a hotspot service
(use this type for external captive portal workflows) or WISPr.
• Guest Access: Click this option if you want guest users to use this WLAN.
After you complete creating this WLAN for guest access, you can start
generating guest passes. For more information about Hotspot 2.0 online
signup, see the Hotspot 2.0 Reference Guide for this release.
