Connecting Data Blades to the Network

Follow these steps to connect the data blades to the network.
1 Connect ETH2 to the router or switch.
2 Obtain two optical fiber (MMF) cables (not supplied).
3 Take one optical fiber cable, and then connect one SFP port on DataPlane0 to
an SFP port on the 10GB router or switch.
4 Take the remaining optical fiber cable, and then connect one SFP port on
DataPlane1 to another SFP port on the router or switch.
NOTE: The dataplane interfaces do not support auto negotiation and must
therefore be connected to 10GB ports on a router or switch.
NOTE: For a list of SFP+ modules that the controller supports, see
Modules.
5 Connect ETH1 to another router or switch to which other controllers (if present)
are connected.
NOTE: Depending on your network setup, you may also connect ETH1 to the same
router or switch to which ETH2 is connected.
Supported SFP+ Modules
Table 11 lists the SFP+ modules that the controller supports. For more information
about these modules, visit the manufacturer's website.
Table 11. SFP+ modules supported by the SCG
Name
Intel Ethernet SFP+ SR (Short
Range) Optics
SmartCell Gateway 200 Getting Started Guide for SmartZone 3.5.1, 800-71517-001 Rev A
Running the Setup Wizard and Logging On to the Web Interface
Product Code Description
E10GSFPSR Dual Rate 10GBASE-SR/1000BASE-
SX with duplex LC connector
Connecting Data Blades to the Network
Supported SFP+
