Table 4. Control panel parts (Continued)
Number
4
5
6
7
8
9
10
11
12

Rear Panel

Figure 5 shows the rear panel of the SCG. For descriptions of the numbered parts,
refer to Table
Figure 5. SCG rear panel
1
8
7
SmartCell Gateway 200 Getting Started Guide for SmartZone 3.5.1, 800-71517-001 Rev A
Description
Fan status LED
Critical alarm (not implemented in this release)
MJR alarm LED (not implemented in this release)
NMI pin hole button (factory reset button)
Chassis ID button
NIC1/NIC2 activity LED
HDD activity LED (flashing green: HDD activity; amber: HDD fault; off: no
access or no HDD fault)
PWR alarm LED (not implemented in this release)
Minor alarm (amber: system unavailable; off: system available)
5.
2
9 10 11 12
Preparing to Set Up the SmartCell Gateway 200
3 4
5
Before You Begin
6
