Front Panel Without the Bezel
Figure 3
shows the front panel of the SCG without the bezel. For descriptions of the
numbered parts, refer to
Figure 3. SCG front panel without the bezel
1
2
Table 2.
SCG front panel parts (without the bezel)
Number
1
2
3
4
5
SmartCell Gateway 200 Getting Started Guide for SmartZone 3.5.1, 800-71517-001 Rev A
Table
2.
Description
ESD ground strap attachment
Hard drive bays (the SCG has two 600GB hard drives)
Control panel (buttons and status indicators, see
Front
Panel)
RJ45 serial port (COM2 / serial B). Use only the console cable provided to
connect this port to another device.
CAUTION!
The SCG has two RJ45 serial ports – one on the front panel
and one on the rear panel. You can only use one of these two ports at any
given time. Using them simultaneously may cause both serial ports to
become unresponsive.
USB port (not used)
Preparing to Set Up the SmartCell Gateway 200
4
3
5
Control Panel on the
Before You Begin
15
